DPO7104C, Enhanced
bandwidth
20 GS/s Analog bandwidth setting
Input Frequency 1.0 GHz 0.5 GHz
10 MHz 6.7 bits 7.2 bits
510 MHz 6.7 bits 7.2 bits
1010 MHz 6.7 bits
10 GS/s Analog bandwidth setting
Input Frequency 1.0 GHz 0.5 GHz
10 MHz 6.6 bits 7.1 bits
510 MHz 6.5 bits 7.1 bits
1010 MHz 6.5 bits
5 GS/s Analog bandwidth setting
Input Frequency 1.0 GHz 0.5 GHz
10 MHz 6.4 bits 7.0 bits
510 MHz 6.4 bits 7.0 bits
1010 MHz 6.3 bits
DPO7104C, Without enhanced
bandwidth
20 GS/s Analog bandwidth setting
Input Frequency 1.0 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 6.4 bits 6.4 bits 6.6 bits 6.7 bits
510 MHz 6.1 bits 6.4 bits
1010 MHz 5.7 bits
10 GS/s Analog bandwidth setting
Input Frequency 1.0 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 6.4 bits 6.4 bits 6.6 bits 6.7 bits
510 MHz 6.3 bits 6.4 bits
1010 MHz 6.3 bits
5 GS/s Analog bandwidth setting
Input Frequency 1.0 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 6.4 bits 6.4 bits 6.6 bits 6.7 bits
510 MHz 6.3 bits 6.4 bits
1010 MHz 6.3 bits
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
26 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
