Tektronix DPO70000C/DX Series - Page 40

Noise typical >20 GHz models
Without enhanced bandwidth
Gain setting, full scale MSO/DPO73304DX MSO/DPO72504DX MSO/DPO72304DX
62.5 mV 0.88 mV 0.83 mV 0.79 mV
100 mV 0.96 mV 0.90 mV 0.86 mV
200 mV 1.53 mV 1.47 mV 1.41 mV
500 mV 4.19 mV 3.57 mV 3.14 mV
1 V 8.30 mV 6.94 mV 6.10 mV
2.0 V 18.84 mV 16.70 mV 14.19 mV
3.0 V 24.64 mV 21.53 mV 19.09 mV
4.0 V 37.91 mV 31.53 mV 26.01 mV
5.0 V 43.36 mV 36.74 mV 31.84 mV
6.0 V 47.93 mV 41.00 mV 36.97 mV
Enhanced bandwidth
Gain setting, full
scale
MSO/DPO73304DX MSO/DPO72504DX MSO/DPO72304DX
100 GS/s 50 GS/s 100 GS/s 50 GS/s 100 GS/s 50 GS/s
62.5 mV 0.84 mV 0.84 mV 0.82 mV 0.90 mV 0.75 mV 0.76 mV
100 mV 0.93 mV 0.93 mV 0.81 mV 0.92 mV 0.78 mV 0.79 mV
150 mV 1.31 mV 1.29 mV 1.17 mV 1.29 mV 1.08 mV 1.19 mV
200 mV 1.52 mV 1.6 mV 1.40 mV 1.56 mV 1.14 mV 1.19 mV
200 mV 2.49 mV 2.52 mV 2.28 mV 2.49 mV 2.10 mV 2.29 mV
400 mV 2.92 mV 2.52 mV 2.80 mV 3.08 mV 2.58 mV 2.29 mV
500 mV 3.55 mV 2.52 mV 3.35 mV 3.75 mV 2.65 mV 2.67 mV
600 mV 4.86 mV 4.86 mV 4.5 mV 4.80 mV 4.14 mV 4.42 mV
700 mV 5.25 mV 5.39 mV 5.04 mV 5.39 mV 4.64 mV 4.96 mV
800 mV 5.76 mV 6.08 mV 5.52 mV 6.00 mV 5.08 mV 5.52 mV
900 mV 5.76 mV 6.66 mV 6.12 mV 6.66 mV 5.63 mV 6.13 mV
1 V 6.80 mV 7.30 mV 6.70 mV 7.20 mV 5.09 mV 5.11 mV
1.1 V 8.69 mV 9.02 mV 8.47 mV 8.91 mV 7.79 mV 8.20 mV
1.2 V 9.12 mV 9.60 mV 9.00 mV 9.48 mV 8.28 mV 8.72 mV
2.0 V 15.4 mV 16.4 mV 12.4 mV 12.9 mV 11.7 mV 11.9 mV
3.0 V 19.9 mV 22.8 mV 17.2 mV 17.7 mV 15.3 mV 15.5 mV
4.0 V 28.8 mV 31.8 mV 24.4 mV 24.9 mV 21.6 mV 21.9 mV
5.0 V 34.3 mV 31.8 mV 28.1 mV 28.7 mV 25.7 mV 25.1 mV
6.0 V 39.8 mV 43.8 mV 34.1 mV 34.8 mV 29.7 mV 30.1 mV
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
