Tektronix DPO70000C/DX Series Technical Reference

Noise, typical, ≥4 GHz ≤20 GHz
models
Without enhanced bandwidth
Gain setting, full scale MSO/ DPO
72004C
MSO/ DPO
71604C
MSO/ DPO
71254C
MSO/ DPO
70804C
MSO/ DPO
70604C
MSO/ DPO
70404C
100 mV 0.87 mV 0.87 mV 0.67 mV 0.58 mV 0.53 mV 0.50 mV
150 mV 1.06 mV 1.06 mV 0.84 mV 0.74 mV 0.73 mV 0.69 mV
200 mV 1.21 mV 1.21 mV 0.98 mV 0.90 mV 0.86 mV 0.86 mV
300 mV 1.82 mV 1.82 mV 1.49 mV 1.34 mV 1.25 mV 1.25 mV
400 mV 2.29 mV 2.29 mV 1.80 mV 1.76 mV 1.67 mV 1.67 mV
500 mV 2.78 mV 2.78 mV 2.29 mV 2.02 mV 2.02 mV 2.02 mV
600 mV 3.35 mV 3.35 mV 2.78 mV 2.52 mV 2.46 mV 2.46 mV
700 mV 3.92 mV 3.92 mV 3.27 mV 3.02 mV 2.90 mV 2.90 mV
800 mV 4.49 mV 4.49 mV 3.76 mV 3.52 mV 3.34 mV 3.34 mV
900 mV 5.14 mV 5.14 mV 4.25 mV 3.87 mV 3.78 mV 3.78 mV
1.0 V 6.48 mV 6.48 mV 4.89 mV 4.50 mV 4.28 mV 4.28 mV
2.0 V 11.47 mV 11.47 mV 8.98 mV 8.80 mV 8.36 mV 8.36 mV
2.5 V 14.04 mV 14.04 mV 11.43 mV 10.81 mV 10.34 mV 10.34 mV
3.0 V 16.61 mV 16.61 mV 13.88 mV 12.82 mV 12.32 mV 12.32 mV
4.0 V 21.83 mV 21.83 mV 18.78 mV 17.36 mV 16.91 mV 16.91 mV
4.5 V 24.41 mV 24.41 mV 21.30 mV 19.44 mV 18.97 mV 18.97 mV
5.0 V 26.99 mV 26.99 mV 23.59 mV 21.51 mV 21.02 mV 21.02 mV
Enhanced bandwidth, sample rates less than 100 GS/s.
MSO/DPO72004C
MSO/DPO71604C
MSO/DPO71254C
where applicable
20 GHz 19 GHz 18 GHz 17 GHz 16 GHz 15 GHz
Gain Setting, full scale
100 mV NA NA 1.09 mV 0.70 mV 0.63 mV 0.59 mV
150 mV NA NA 1.06 mV 0.93 mV 0.75 mV 0.79 mV
200 mV 2.08 mV 1.67 mV 1.34 mV 1.09 mV 0.88 mV 0.92 mV
300 mV 3.70 mV 2.35 mV 1.90 mV 1.57 mV 1.35 mV 1.31 mV
400 mV 4.18 mV 3.10 mV 2.53 mV 2.08 mV 1.68 mV 1.67 mV
500 mV 3.55 mV 3.10 mV 2.61 mV 2.29 mV 2.04 mV 2.02 mV
600 mV 5.06 mV 3.70 mV 3.13 mV 2.78 mV 2.45 mV 2.46 mV
700 mV 6.09 mV 4.30 mV 3.65 mV 3.27 mV 2.99 mV 2.90 mV
800 mV 6.62 mV 4.90 mV 4.16 mV 3.76 mV 3.40 mV 3.34 mV
900 mV 7.21 mV 5.31 mV 4.57 mV 4.16 mV 3.71 mV 3.59 mV
1.0 V 10.52 mV 8.35 mV 7.98 mV 5.32 mV 4.55 mV 4.50 mV
2.0 V 21.38 mV 15.54 mV 12.66 mV 10.28 mV 8.33 mV 8.70 mV
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 29
