Enhanced bandwidth, at 100 GS/s.
MSO/DPO72004C
MSO/DPO71604C
MSO/DPO71254C
20 GHz 19 GHz 18 GHz 17 GHz 16 GHz 15 GHz
Gain Setting, full scale
100 mV N/A N/A 0.981 mV 0.63 mV 0.5706 mV 0.531 mV
150 mV N/A N/A 0.954 mV 0.837 mV 0.729 mV 0.711 mV
200 mV 1.736 mV 1.4195 mV 1.139 mV 0.9265 mV 0.816 mV 0.782 mV
300 mV 2.92 mV 1.9975 mV 1.615 mV 1.3345 mV 1.156 mV 1.1135 mV
400 mV 3.072 mV 2.635 mV 2.1506 mV 1.768 mV 1.53 mV 1.4195 mV
500 mV 2.944 mV 2.635 mV 2.2185 mV 1.9465mV 1.802 mV 1.717 mV1.802 m
V
600 mV 3.784 mV 3.145 mV 2.6605 mV 2.363 mV 2.176 mV 2.091 mV
700 mV 4.424 mV 3.655 mV 3.1025 mV 2.7795 mV 2.737 mV 2.465 mV
800 mV 4.704 mV 4.165 mV 3.536 mV 3.196 mV 2.9155 mV 2.839 mV
900 mV 5.296 mV 4.5135 mV 3.8845 mV 3.536 mV 3.196 mV 3.0515 mV
1.0 V 8.688 mV 7.0975 mV 6.783 mV 4.522 mV 4.0545 mV 3.825 mV
2.0 V 15.352 mV 13.209 mV 10.761 mV 8.738 mV 7.735 mV 7.395 mV
2.5 V 17.392 mV 15.1895 mV 12.597 mV 10.421mV 9.248 mV 8.9335 mV
3.0 V 19.432 mV 17.17 mV 14.348 mV 12.104 mV 11.407 mV 10.742 mV
4.0 V 25.736 mV 21.131 mV 17.9945 mV 15.521mV 15.2575 mV 13.583 mV
4.5 V 27.52 mV 23.12 mV 19.7965 mV 17.2125 mV 16.184 mV 15.13 mV
5.0 V 30.064 mV 25.1005 mV 21.5985 mV 18.8955 mV 18.0795 mV 16.6685 mV
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 35
