Tektronix DPO70000C/DX Series Technical Reference

MSO/DPO72004C
MSO/DPO71604C
MSO/DPO71254C
14 GHz 13 GHz 12.5 GHz 12 GHz 11 GHz 10 GHz
Gain Setting, full scale
100 mV 0.522 mV 0.493 mV 0.4675 mV 0.4505 mV 0.4335 mV 0.4165 mV
150 mV 0.693 mV 0.6205 mV 0.612 mV 0.6035 mV 0.578 mV 0.5525 mV
200 mV 0.7395 mV 0.714 mV 0.697 mV 0.6885 mV 0.663 mV 0.6375 mV
300 mV 1.088 mV 1.071 mV 1.088 mV 1.02 mV 0.986 mV 0.935 mV
400 mV 1.3855 mV 1.3515 mV 1.4195 mV 1.2665 mV 1.2155 mV 1.1815 mV
500 mV 1.632 mV 1.5725 mV 1.53 mV 1.513 mV 1.462 mV 1.4025 mV
600 mV 1.9975 mV 1.9295 mV 2.057 mV 1.853 mV 1.802 mV 1.6915 mV
700 mV 2.3715 mV 2.2865 mV 2.499 mV 2.193 mV 2.1335 mV 1.989 mV
800 mV 2.7455 mV 2.635 mV 2.89 mV 2.533 mV 2.465 mV 2.363 mV
900 mV 2.9835mV 2.8815mV 3.0855 mV 2.7795mV 2.669 mV 2.567 mV
1.0 V 3.621 mV 3.587 mV 3.4765 mV 3.4425 mV 3.349 mV 3.1705 mV
2.0 V 6.9955 mV 6.766 mV 7.1315 mV 6.3495 mV 6.086 mV 5.8905 mV
2.5 V 8.4575 mV 8.177 mV 8.1345 mV 7.6755 mV 7.378 mV 7.0975 mV
3.0 V 9.928 mV 9.5795 mV 10.4975 mV 8.993 mV 8.6615 mV 8.177 mV
4.0 V 12.9115 mV 13.039 mV 14.671 mV 12.5715 mV 12.1465 mV 11.56 mV
4.5 V 14.382 mV 14.5265 mV 15.7165 mV 13.9995 mV 13.5405 mV 12.852 mV
5.0 V 15.861 mV 16.0055 mV 16.66 mV 15.4275 mV 14.926 mV 14.1525 mV
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
36 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
