Tektronix DPO70000C/DX Series Technical Reference

MSO/DPO72004C
MSO/DPO71604C
MSO/DPO71254C
9 GHz 8 GHz 7GHz 6 GHz 5 GHz 4 GHz
Gain Setting, full scale
100 mV 0.391 mV 0.3825 mV 0.387 mV 0.36 mV 0.333 mV 0.306 mV
150 mV 0.5355 mV 0.51 mV 0.513 mV 0.486 mV 0.459 mV 0.432 mV
200 mV 0.6035 mV 0.5695 mV 0.5355 mV 0.51 mV 0.4845 mV 0.4505 mV
300 mV 0.8755 mV 0.8415mV 0.8075 mV 0.7565mV 0.714 mV 0.6545 mV
400 mV 1.1305 mV 1.0795 mV 1.003 mV 0.935 mV 0.901 mV 0.833 mV
500 mV 1.3345 mV 1.258 mV 1.1985 mV 1.1135 mV 1.037 mV 0.935 mV
600 mV 1.6065 mV 1.5215 mV 1.4535 mV 1.36 mV 1.2665 mV 1.1475 mV
700 mV 1.8785 mV 1.7935 mV 1.7085 mV 1.598 mV 1.496 mV 1.3515 mV
800 mV 2.2185 mV 2.1165 mV 2.0145 mV 1.9125 mV 1.768 mV 1.666 mV
900 mV 2.431 mV 2.329 mV 2.2185 mV 2.0825mV 1.9465mV 1.768 mV
1.0 V 2.431 mV 2.329 mV 2.2185 mV 2.0825mV 1.9465mV 1.768 mV
2.0 V 5.5675 mV 5.3805 mV 5.049 mV 4.6835 mV 4.488 mV 4.165 mV
2.5 V 6.732 mV 6.4855 mV 6.12 mV 5.678 mV 5.389 mV 4.9555 mV
3.0 V 7.905 mV 7.5905 mV 7.191 mV 6.664 mV 6.29 mV 5.7545 mV
4.0 V 11.0585mV 10.54 mV 10.0385 mV 9.4095 mV 8.8145 mV 8.0835 mV
4.5 V 12.325 mV 11.73 mV 11.1945 mV 10.489 mV 9.8005 mV 8.959 mV
5.0 V 13.583 mV 12.92 mV 12.3505 mV 11.5685 mV 10.778 mV 9.8345 mV
MSO/DPO72004C MSO/
DPO71604C MSO/
DPO71254C
3 GHz 2 GHz 1GHz 500 MHz
Gain Setting, full scale
100 mV 0.279 mV 0.234 mV 0.18 mV 0.153 mV
150 mV 0.396 mV 0.351 mV 0.306 mV 0.243 mV
200 mV 0.408 mV 0.374 mV 0.3145 mV 0.2635 mV
300 mV 0.5865 mV 0.5185mV 0.442 mV 0.374 mV
400 mV 0.748 mV 0.663 mV 0.561 mV 0.4845 mV
500 mV 0.8755 mV 0.7735 mV 0.646 mV 0.578 mV
600 mV 1.054 mV 0.9265 mV 0.7735 mV 0.697 mV
700 mV 1.2325 mV 1.0795 mV 0.901 mV 0.8075 mV
800 mV 1.496 mV 1.2835 mV 1.037 mV 0.935 mV
900 mV 1.598 mV 1.3855mV 1.1475 mV 1.037 mV
1.0 V 1.598 mV 1.3855mV 1.1475 mV 1.037 mV
2.0 V 3.7655 mV 3.502 mV 2.907 mV 2.448 mV
2.5 V 4.5305 mV 4.1395 mV 3.4595 mV 2.9665 mV
3.0 V 5.287 mV 4.7855 mV 4.012 mV 3.485 mV
4.0 V 7.5055 mV 6.681 mV 5.6355 mV 4.981 mV
4.5 V 8.3385 mV 7.738 mV 6.239 mV 5.5505 mV
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 37
