Tektronix DPO70000C/DX Series Technical Reference

40 GS/s
Step gain 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
100 mV/div 6.3 mV 3.8 mV 3.2 mV 3.0 mV
50 mV/div 2.4 mV 1.75 mV 1.6 mV 1.5 mV
20 mV/div 1.07 mV 0.7 mV 0.63 mV 0.595 mV
10 mV/div 0.61 mV 0.38 mV 0.32 mV 0.3 mV
5 mV/div 0.41 mV 0.24 mV 0.18 mV 0.151 mV
2 mV/div 0.19 mV 0.18 mV 0.115 mV 0.065 mV
1 mV/div 0.12 mV 0.12 mV 0.115 mV 0.045 mV
20 GS/s
Step gain 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
500 mV/div 23.0 mV 16.3 mV 14.5 mV 14.0 mV
200 mV/div 10.5 mV 6.9 mV 6.1 mV 5.8 mV
100 mV/div 6.25 mV 3.8 mV 3.2 mV 3.0 mV
50 mV/div 2.4 mV 1.75 mV 1.6 mV 1.5 mV
20 mV/div 1.04 mV 0.7 mV 0.63 mV 0.595 mV
10 mV/div 0.605 mV 0.38 mV 0.32 mV 0.3 mV
5 mV/div 0.4 mV 0.24 mV 0.18 mV 0.151 mV
2 mV/div 0.19 mV 0.18 mV 0.115 mV 0.065 mV
1 mV/div 0.12 mV 0.12 mV 0.115 mV 0.045 mV
10 GS/s
Step gain 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
500 mV/div 22.8 mV 16.3 mV 14.5 mV 14.0 mV
200 mV/div 10.4 mV 6.9 mV 6.1 mV 5.8 mV
100 mV/div 6.15 mV 3.8 mV 3.2 mV 3.0 mV
50 mV/div 2.4 mV 1.75 mV 1.6 mV 1.5 mV
20 mV/div 1.035 mV 0.7 mV 0.63 mV 0.595 mV
10 mV/div 0.59 mV 0.38 mV 0.32 mV 0.3 mV
5 mV/div 0.395 mV 0.24 mV 0.18 mV 0.151 mV
2 mV/div 0.19 mV 0.18 mV 0.115 mV 0.065 mV
1 mV/div 0.12 mV 0.12 mV 0.115 mV 0.045 mV
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
40 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series

Tektronix DPO70000C/DX Series Specifications

General

Brand	Tektronix
Model	DPO70000C/DX Series
Category	Test Equipment
Language	English
