Tektronix DPO70000C/DX Series Technical Reference

DPO7254C Enhanced
bandwidth
40 GS/s
Step gain 2.5 GHz 2.0 GHz 1.0 GHz 0.5 GHz
500 mV/div 19.7 mV 16.2 mV 12.1 mV 9.9 mV
200 mV/div 8.71 mV 6.97 mV 4.97 mV 4.0 mV
100 mV/div 5.23 mV 4.25 mV 2.97 mV 2.36 mV
50 mV/div 2.0 mV 1.64 mV 1.23 mV 1.03 mV
20 mV/div 0.866 mV 0.707 mV 0.528 mV 0.431 mV
10 mV/div 0.523 mV 0.425 mV 0.297 mV 0.236 mV
5 mV/div 0.343 mV 0.349 mV 0.21 mV 0.154 mV
2 mV/div 0.135 mV 0.135 mV 0.135 mV 0.135 mV
1 mV/div 0.095 mV 0.095 mV 0.095 mV 0.095 mV
20 GS/s
Step gain 2.5 GHz 2.0 GHz 1.0 GHz 0.5 GHz
500 mV/div 19.5 mV 16.1 mV 12.0 mV 9.8 mV
200 mV/div 8.7 mV 7.05 mV 5.1 mV 4.0 mV
100 mV/div 5.15 mV 4.2 mV 2.95 mV 2.35 mV
50 mV/div 2.0 mV 1.65 mV 1.25 mV 1.05 mV
20 mV/div 0.855 mV 0.71 mV 0.52 mV 0.425 mV
10 mV/div 0.515 mV 0.42 mV 0.295 mV 0.235 mV
5 mV/div 0.34 mV 0.345 mV 0.21 mV 0.155 mV
2 mV/div 0.135 mV 0.135 mV 0.135 mV 0.135 mV
1 mV/div 0.095 mV 0.095 mV 0.095 mV 0.095 mV
10 GS/s
Step gain 2.5 GHz 2.0 GHz 1.0 GHz 0.5 GHz
500 mV/div 20.2 mV 16.7 mV 12.5 mV 10.3 mV
200 mV/div 8.9 mV 7.3 mV 5.3 mV 4.16 mV
100 mV/div 5.3 mV 4.3 mV 3.05 mV 2.4 mV
50 mV/div 2.1 mV 1.7 mV 1.3 mV 1.1 mV
20 mV/div 0.88 mV 0.74 mV 0.55 mV 0.435 mV
10 mV/div 0.52 mV 0.43 mV 0.3 mV 0.24 mV
5 mV/div 0.345 mV 0.33 mV 0.21 mV 0.155 mV
2 mV/div 0.135 mV 0.135 mV 0.135 mV 0.135 mV
1 mV/div 0.095 mV 0.095 mV 0.095 mV 0.095 mV
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 41
