Tektronix DPO70000C/DX Series Technical Reference

DPO7254C Without enhanced
bandwidth
40 GS/s
Step gain 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
500 mV/div 22.7 mV 16.4 mV 15.0 mV 14.5 mV
200 mV/div 9.84 mV 6.97 mV 6.2 mV 5.8 mV
100 mV/div 5.89 mV 3.74 mV 3.2 mV 2.9 mV
50 mV/div 2.31 mV 1.69 mV 1.55 mV 1.45 mV
20 mV/div 0.964 mV 0.697 mV 0.63 mV 0.59 mV
10 mV/div 0.574 mV 0.379 mV 0.325 mV 0.295 mV
5 mV/div 0.4 mV 0.231 mV 0.175 mV 0.145 mV
2 mV/div 0.19 mV 0.195 mV 0.12 mV 0.065 mV
1 mV/div 0.12 mV 0.12 mV 0.12 mV 0.045 mV
20 GS/s
Step gain 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
500 mV/div 21.8 mV 16.0 mV 15.0 mV 14.5 mV
200 mV/div 9.6 mV 6.8 mV 6.2 mV 5.8 mV
100 mV/div 5.7 mV 3.65 mV 3.2 mV 2.9 mV
50 mV/div 2.25 mV 1.65 mV 1.55 mV 1.45 mV
20 mV/div 0.94 mV 0.68 mV 0.63 mV 0.49 mV
10 mV/div 0.56 mV 0.37 mV 0.325 mV 0.295 mV
5 mV/div 0.38 mV 0.225 mV 0.175 mV 0.145 mV
2 mV/div 0.19 mV 0.195 mV 0.12 mV 0.065 mV
1 mV/div 0.12 mV 0.12 mV 0.12 mV 0.045 mV
10 GS/s
Step gain 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
500 mV/div 21.8 mV 16.0 mV 15.0 mV 15.5 mV
200 mV/div 9.6 mV 6.8 mV 6.2 mV 5.8 mV
100 mV/div 5.65 mV 3.65 mV 3.2 mV 2.9 mV
50 mV/div 2.2 mV 1.65 mV 1.55 mV 1.45 mV
20 mV/div 0.94 mV 0.68 mV 0.63 mV 0.59 mV
10 mV/div 0.56 mV 0.37 mV 0.325 mV 0.295 mV
5 mV/div 0.37 mV 0.225 mV 0.175 mV 0.145 mV
2 mV/div 0.19 mV 0.195 mV 0.12 mV 0.065 mV
1 mV/div 0.12 mV 0.12 mV 0.12 mV 0.045 mV
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
42 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
