About This Guide
This demonstration guide takes you through a series of
step-by-step demonstrations on how the MDO3000 Series
oscilloscope helps simplify the debug of mixed signal designs
with its powerful functionality and integrated test instruments.
This oscilloscope can help you discover new ways to quickly
debug some of today’s most challenging and common design
problems.
Note: There are additional built-in product demos in
MDO3000. To explore other product demos and features,
press Utility front panel button, then press MDO3000 Utility
Page lower-bezel button and use Multipurpose a to select
Demo.
To go through the exercises, you need:
MDO demonstration board (includes a USB Y-cable used
to power the demo board) with waveforms that represent
a number of mixed-signal challenges facing today’s
designers. To find the desired signal on the demo board,
refer to the “Locating Signals” section at the end of this
demonstration guide.
BNC cable to connect AFG output to analog channel and
to connect to the spectrum analyzer input.
N-BNC adapter to connect BNC cable to RF input channel
(standard accessory)
Serial bus triggering and analysis application modules
DVM, AFG, Spectrum Analyzer options
Note: For demonstration purpose, all application modules
and options are enabled in MDO3000 demo units. They are
listed on the following page:
www.tektronix.com/mdo30006
MDO3000 Series Oscilloscope
Demonstration Guide
