Tektronix MDO32 Declassification And Security Instructions

Nonvolatile memory devices
Flash 2 GB - Internal use only
Type and size eMMC Flash 2 GB
Function Holds instrument calibration data, serial number, option key, instrument operating system, and
application software.
Type of user information
stored
None
Method of modification Indirectly
Data input method Firmware operations, user input
Location Main board
User accessible No
Flash 2 GB - External use only
Type and size eMMC Flash 2 GB
Function Holds all user-storable data, such as waveforms, setups, measurement results, and instrument
settings.
Type of user information
stored
User data, user settings
Method of modification Directly
Data input method Firmware operations, user input
Location Main board
User accessible No
Process to clear/sanitize Use the procedure Use TekSecure to erase memory contents on page 12 to erase reference
waveforms and instrument setups. Then use the procedure Disable the LAN port and clear the LAN
Ethernet settings on page 8 to disable the LAN ethernet and to clear information, such as IP
addresses.
Serial real-time clock
Type and size Serial real-time clock
Function Real-time clock with battery backup
Type of user information
stored
Time/date
Method of modification Indirectly
Data input method Not applicable
Location Main board
User accessible Not applicable
To clear Not applicable, no user data
Process to sanitize Not applicable, no user data
EEPROM
Type and size EEPROM 1 Kbit
Function Holds signal generator calibration data
Memory devices
3 Series MDO Declassification and Security Instructions 3
