Installation
2. Push Utility.
3. Push Utility Page.
Utility
Page
4. Turn multipurpose knob a and select I/O.
5. Push Socket Server.
Utility
Page
I/O
USB
Computer
Ethernet &
LXI
Network
Configura-
tion
Manual
Socket
Server
GPIB
1
Socket
Server
6. On the resulting Socket Server side menu,
push the top entry to highlight Enabled.
Enabled
Disabled
7. Choose whether the protocol should be
None or Terminal.
Acomm
unication session run by a human
at a keyboard typically uses a terminal
protocol. An automated session might
hand
le its own communications without such
protocol from the oscilloscope.
Proto
col
None
Terminal
Current
Port 4000
8. If required, change the port number by
rotating multipurpose knob a.
Select Port
(a) 4
000
9. If required, press OK to set the new port
number.
OK
Set
Port
30 MDO4000 Series Oscilloscopes User Manual
