Display Wavefor
mData
5. Push Label to create a label for the channel.
(See page 41, Labeling Channels and
Buses.)
6. Push Probe Setup to define probe
parameters.
On the resulting side-bezel menu:
Select Voltage or Current to set the
probe type for probes that do not have
the TekProb
e II or TekVPI interface.
Use multipu
rpose knob a to set the
attenuation to match the probe.
7. Push More to access additional side-bezel
menus.
82 MSO2000B and DPO2000B Series Oscilloscopes User Manual
