Display Wavefor
mData
3. Turn multipur
pose knob a and select
Display.
Utility
Page
Display
Backlight
Intensity
High
Graticule
Full
Screen
Annotation
4. Push Screen Annotation from the resulting
lower-bezel menu.
5. Push Display Annotation to select On from
the side-be
zel menu.
The annotation window now appears.
Position it by turning multipurpose knobs a
and b.
6. Push Edit Annotation from the side-bezel
menu. You c
an add up to 1,000 characters
or a full screen.
7. Turn multipurpose knob a to scroll through
the list o
f letters, numbers, and other
characters to select each desired character.
Alternatively, use a USB keyboard to type
in chara
cters. (See page 25, Connecting a
USB Keyboard to Your Oscilloscope.)
To reposition the annotated text, press
the side
-bezel Position button and turn
multipurpose knobs a and b, as desired.
88 MSO2000B and DPO2000B Series Oscilloscopes User Manual
