Save and Recall I
nformation
Save
Setup
To File
Edit Labels
3. From the resul
ting side-bezel menu, select
the location to save the setup to or to recall
it from.
To save setup i
nformation to one of the ten
internal setup memories in the oscilloscope,
push the appropriate side-bezel button.
To save setup
information to a USB file,
push the To File button.
To Setup 1
To Setup 2
–more–
4. IfyouaresavinginformationtoaUSBflash
drive, tur
n multipurpose knob a to scroll
through the file structure. (See page 111,
External File Structure.)
Push S elect to open or close file folders.
Push the Menu Off button to cancel the
save operation.
MSO2000B and DPO2000B Series Oscilloscopes User Manual 117
