Installation
Random Vibrati
on:
Operating: 0.31 G
RMS
, 5 - 500 Hz, 10 minutes per axis, 3 axes (30 minutes total)
Non-operating: 2.46 G
RMS
, 5 - 500 Hz, 10 minutes per axis, 3 axes (30 minutes total)
Pollution Degree: 2, Indoor use only
CAUTION. To ensure proper cooling, keep the sides and rear of the oscilloscope clear of obstructions.
TPP0200/TPP0100 Pa
ssive Probe
Single-ended volt
age probe (ground referenced):
300 V
RMS
CAT II safety requirements
Installation Category II - for m easurem ents performed on circuits directly connected to the low-voltage installation
Temperature:
Operating: -10 °C to +55 °C (+14 °F to +131 °F)
Nonoperating: -5
1 °C to +71 °C ( -60 °F to +160 °F)
Pollution Degree: 2, Indoor use only
Humidity: 5% to 95% RH
MSO2000B Series Oscilloscope with a P6316 Digital Probe
Threshold Accuracy: ±(100 mV + 3% of threshold)
Threshold Range: ±20 V
Maximum nond
estructive input signal to probe: ±40 V
Minimum signal swing: 500 mV
peak-to-peak
Input resistance: 101 k
Input capacitance: 8.0 pF
Temperat
ure:
Operating: 0 °C to +50 °C (+32 °F to +122 °F)
Nonoperating: -40 °C to +71 °C (-40 °F to +160 °F)
Altitude:
Operating: 3,000 m (9,843 ft) maximum
Nonoper
ating: 12,000 m (39,370 ft) maximum
Pollution Degree: 2, Indoor use only
6 MSO2000B and DPO 2000B Series Oscilloscopes User Manual
