Acquire the Sign
al
2. Push Trigger Me
nu and enter trigger
parameters. (See page 67, Choosing a
Trigger Type.)
You c an displa
y bus information without
triggering on the bus signal.
SettingUpBusParameters
NOTE. For all serial bus sources, use any combination of channels 1 through 4, and D15 through D0.
To trigger on serial or parallel bus conditions, refer to Triggering on Buses. (See page 70, Triggering on Buses.)
50 MSO2000B and DPO2000B Series Oscilloscopes User Manual
