Giving Demos of MSO Features
Demo XXIII: Zooming in on White Edges (MSO4000 Only)
White vertical edges on displayed digital waveforms inform the user that more information is available at that point in the display.
You can zoo m in on these white edges to see more details.
NOTE. Run this demo with an M SO41 04, MSO4054, or MSO4034.
104 Demo 2 Board Instruction Manual
