Giving Demos of MSO Features
4. When done, push Menu Off and admire your
list of labels on the screen.
Demo XX: Exploring Parallel Buses (MSO2000, MSO3000, and M SO4000 Models)
All MSO4000, MSO3000, and MSO2000 series oscilloscopes are designed to efficiently analyze parallel buses, such as those used
in embedded circuits. The MSO’s bus, triggering, and searching capab ilities all support parallel bus analysis.
1. Push the B1 button.
