Getting Started with the MSO/DPO2000 , M SO/DPO30 00, and MSO/DPO4000 Series Oscilloscopes
4. Push Cursors two more times to turn them
off.
Demo VII: Taking Measurements
1. Push the front-panel Measure button.
2. Push the lower-bezel Add Measurement
button.
Add Mea-
surement
Remove
Measure-
ment
Indicators
More
Bring
Cursors on
Screen
Configure
Cursors
14 Demo 2 Board Instruction Manual
