Giving Demos of Advanced Oscilloscope Features
You are now looking at the clock (yellow
ch1) and data (blue ch2) lines of an I
2
C
bus.
Hint: If the waveforms do not look anyt hing
like the display to the right, go back to step
1andconfirm that you connected both
probes to the correct pins on the Demo 2
board.
30 Demo 2 Board Instruction Manual
