Tektronix MSO2012

Giving Demos of A dvanced Oscillosco pe Features
2. Push Default Setup.
3. Push Autoset.
4. Push Acquire.
5. Push the lower-bezel menu Record Length
button (if not already active) and the side-bezel
menu 1M p oints button.
Mode
Sample
Record
Length
1M
Reset
Horizontal
Position
Waveform
Display
Demo 2 Board Instruction Manua l 61
