Specifications
Table 10: Mecha
nical specifications
Characteristic Description
Dimensions Nominal, non-
rack mount:
Height:
Handle down: 175 mm (6.89 in)
Handle up: 18
0 mm (7.09 in)
Depth:
Handle down: 146 mm (5.74 in)
Handle up: 1
34 mm (5.29 in)
Width: 377 mm (14.85 in) from handle hub to handle hub
Weight Nominal, n
on-rack mount:
Stand-alone instrument: 3.6 kg (7.9 lbs)
Packaged for domestic shipment: 6.2 kg (13.7 lbs)
Cooling method Forced air cooled, one fan
Clearance Requirements The clearance requirement for adequate cooling is:
50 mm (2 in
) on the left side (when looking a t the front of the instrument)
DPO2000 and MSO2000 Series Specifications and Performance Verification 9
