Tektronix MSO2012 Technical Reference

Performance Verification
Test Record
Model Serial Procedure performed by Date
Test Passed Failed
Self Test
Signal Path Compensation (SPC)
Performance Checks
DC Balance
Channel Coupling Low limit Test result High limit
DC
-21 mV 21 mV
Channel 1
GND
-21 mV 21 mV
DC
-21 mV 21 mV
Channel 2
GND
-21 mV 21 mV
DC
-21 mV 21 mV
Channel 3
1
GND
-21 mV 21 mV
DC
-21 mV 21 mV
Channel 4
1
GND
-21 mV 21 mV
1
Channels 3 and 4 are only on four channel oscilloscopes
DC Gain Accuracy
Channel Vertical scale Low limit Test result High limit
5 mV/div
33.6 mV 36.4 mV
200 mV/div
1.358 V 1.442 V
Channel 1
2V/div
13.58 V 14.42 V
5 mV/div
33.6 mV 36.4 mV
200 mV/div
1.358 V 1.442 V
Channel 2
2V/div
13.58 V 14.42 V
5 mV/div
33.6 mV 36.4 mV
200 mV/div
1.358 V 1.442 V
Channel 3
1
2V/div
13.58 V 14.42 V
5 mV/div
33.6 mV 36.4 mV
200 mV/div
1.358 V 1.442 V
Channel 4
1
2V/div
13.58 V 14.42 V
1
Channels 3 and 4 are only on four channel oscilloscopes
DPO2000 and MSO2000 Series Specifications and Performance Verification 13
