Tektronix MSO2012 Technical Reference

Performance Verification
Bandwidth
Channel Low limit Test result High limit
Channel 1
2.12 V
——
Channel 2
2.12 V
——
Channel 3
1
2.12 V
——
Channel 4
1
2.12 V
——
1
Channels 3 and 4 are only on four channel oscilloscopes
Vertical Position Range
Channel V/div setting
Trace
position Offset DC Voltage source Pass/Fail
Top –1 V –1.800 V
200 mV/div
Bottom +1 V +1.800 V
Top –25 V –45.0 V
Channel 1
5V/div
Bottom +25 V +45.0 V
Top –1 V -1.800 V
200 mV/div
Bottom +1 V +1.800 V
Top –25 V –45.0 V
Channel 2
5V/div
Bottom +25 V +45.0 V
Top –1 V –1.800 V
200 mV/div
Bottom +1 V +1.800 V
Top –25 V –45.0 V
Channel 3
1
5V/div
Bottom +25 V +45.0 V
Top –1 V –1.800 V
200 mV/div
Bottom +1 V +1.800 V
Top –25 V –45.0 V
Channel 4
1
5V/div
Bottom +25 V +45.0 V
1
Cha
nnels 3 and 4 are only on four channel oscilloscopes.
Sample Rate and Delay Time Accuracy Low limit Test result High limit
Sample Rate and Delay Time Accuracy
-2.5 divisions +2.5 divisions
14 DPO2000 and MSO2000 Series Specifications and Performance Verifi cation
