Tektronix MSO2014 Programmer's Manual

Command Groups
Search Commands (cont.)
Command Description
SEARCH:SEARCH<x>:TRIGger:A:LOGIc:
THReshold:REF<x>
Sets or returns the reference w aveform
threshold level for logic search
SEARCH:SEARCH<x>:TRIGger:A:
LOWerthreshold:CH<x>
Sets or returns the lower waveform threshold
level for all channel waveform searches
SEARCH:SEARCH<x>:TRIGger:A:
LOWerthreshold:MATH
Sets or returns the lower waveform threshold
level for all math waveform searches
SEARCH:SEARCH<x>:TRIGger:A:
LOWerthreshold:REF<x>
Sets or returns the lower waveform threshold
level for all reference waveform searches
SEARCH:SEARCH<x>:TRIGger:A:
PULSEWidth:POLarity
Sets or returns the polarity for a pulse search
SEARCH:SEARCH<x>:TRIGger:A:
PULSEWidth:SOUrce
Sets or returns the source waveform for a
pulse search
SEARCH:SEARCH<x>:TRIGger:A:
PULSEWidth:WHEn
Sets or returns the condition for generating
a pulse width search
SEARCH:SEARCH<x>:TRIGger:A:
PULSEWidth:WIDth
Sets or returns the pulse width setting for a
pulse width search
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
POLarity
Sets or returns the polarity setting for a runt
search
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
SOUrce
Sets or returns the source setting for a runt
search
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
WHEn
Sets or returns the condition setting for a runt
search
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
WIDth
Sets or returns the width setting for a runt
search
SEARCH:SEARCH<x>:TRIGger:A:
SETHold:CLOCk:EDGE
Sets or returns the clock slope setting for a
setup/hold search
SEARCH:SEARCH<x>:TRIGger:A:
SETHold:CLOCk:SOUrce
Sets o r returns the clock source setting for
an setup/hold search
SEARCH:SEARCH<x>:TRIGger:A:
SETHold:CLOCk:THReshold
Sets or r eturns the clock threshold setting for
an setup/hold search
SEARCH:SEARCH<x>:TRIGger:A:
SETHold:DATa:SOUrce
Sets or returns the data source setting for
an setup/hold search
SEARCH:SEARCH<x>:TRIGger:A:
SETHold:DATa:THReshold
Sets or returns the data threshold setting for
an setup/hold search
SEARCH:SEARCH<x>:TRIGger:A:
SETHold:THReshold:CH<x>
Sets or returns the trigger search setup and
hold lower threshold to determine where to
place a mark. Ch<x> is the channel number
SEARCH:SEARCH<x>:TRIGger:A:
SETHold:THReshold{:MATH|:MATH1}
Sets or returns the trigger search setup and
hold lower threshold to determine where to
place a mark
2-36 MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual
