Display Wavefor
mData
2. Push the lower-bezel D15–D0 On/Off menu
item.
D15–D0
On/Off
Thresholds Edit Labels Height
S |ML
3. Push Select, and turn multipurpose knob a
to select a channel from the list. Then push
Display to t
urn on (or turn off) the waveform.
You can see groups at the end of the
list by turning multipurpose knob a fully
countercl
ockwise.
Select
(a) D0
(b) 1.04 div
Display
On|Off
Push the appropriate side-bezel button to
turn on all the channels in the D7–D0 group
or in the D
15–D8 group.
Turn on
D7–D0
Turn on
D15–D8
To posit
ion and group digital channels, follow
these steps:
1. Push the front-panel D15–D0 button.
2. Turn multipurpose knob a to select the
channe
l or group to move.
3. To group some or all of the channels, select
and move the channels next to each other
in the display.
MSO2000B and DPO2000B Series Oscilloscopes User Manual 85
