Tektronix MSO44 Instructions

How to sanitize a nonfunctional instrument
9.
Reassemble the instrument by using the disassembly steps in reverse order. Tighten the Torx T-10 screws to 0.65
Newton meters.
10.
Package the reassembled instrument, minus the Processor board, and ship to your nearest Tektronix Service Center
for repairs. A new Processor board will be installed
Repair charges
Replacement of damaged and missing hardware is charged according to the rate at the time of replacement.
14 4 Series MSO Opt. 4–SEC Declassification and Security Instructions

Tektronix MSO44 Specifications

General

Bandwidth	200 MHz, 350 MHz, 500 MHz, 1 GHz
Analog Channels	4
Operating Temperature	0 °C to +50 °C
Sample Rate	6.25 GS/s
Record Length	62.5 Mpoints
Input Impedance	1 MΩ ±1%, 50 Ω ±1%
Vertical Resolution	12 bits
Waveform Capture Rate	Up to 500, 000 wfm/s
Maximum Input Voltage	5 VRMS (50 Ω)
Probe Interface	TekVPI
Digital Channels	16 (optional)
