Preface
About the 4-SEC option
Option 4-SEC provides the highest level of instrument security for the products. Option features include:
Oscilloscope hardware is configured to easily declassify the oscilloscope:
There is no user access to the internal storage to store or save any user data to the oscilloscope memory
Data can only be saved to or read from a USB port on the instrument, a mounted network drive, or through the
programmatic interface
Password p rotection to enable/disable external USB Host, USB Device and Ethernet communication ports
Password protection to enable/disable firmware upgrades or downgrades
Password protection to prevent booting from USB flash devices.
NOTE.
Option 4-SEC must be ordered at the same time you order an instrument.
iv 4 Series MSO Opt. 4–SEC Declassification and Security Instructions

Tektronix MSO44 Specifications

General

Bandwidth	200 MHz, 350 MHz, 500 MHz, 1 GHz
Analog Channels	4
Operating Temperature	0 °C to +50 °C
Sample Rate	6.25 GS/s
Record Length	62.5 Mpoints
Input Impedance	1 MΩ ±1%, 50 Ω ±1%
Vertical Resolution	12 bits
Waveform Capture Rate	Up to 500, 000 wfm/s
Maximum Input Voltage	5 VRMS (50 Ω)
Probe Interface	TekVPI
Digital Channels	16 (optional)
