Table 6: Front cover and rear case
Index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont'd
Qty Name & description
Figure 4: Front cover and rear case exploded view on page
27
-1 016-2106-XX 1 CASE, ACCESSORY FRONT COVER
-2 200-5406-XX 1 COVER, FRONT PROTECTIVE
-3 050-3895-XX 1 KIT;MSO5 SERIES HANDLE HUB LEFT
-4 065-1007-XX 1 MODULE ASSY:SERVICE REPLACEMENT KIT;REAR CASE
W/ POWER SPRING CLIPS AND STAND-OFFS; SAFETY
CONTROLLED
-5 220-0325-XX 6 INSERT, 2.5MM, SNAP IN
-6 335-3850-XX 1 MARKER, IDENTIFICATION, SERVICE US PLUS, ENGLISH
335-3851-XX 1 MARKER, IDENTIFICATION, SERVICE EUROPE, ENGLISH
335-3852-XX 1 MARKER, IDENTIFICATION, SERVICE JAPAN, JAPANESE
335-3853-XX 1 MARKER, IDENTIFICATION, SERVICE CHINA, SIMPLIFIED
CHINESE
335-3854-XX 1 MARKER, IDENTIFICATION, SERVICE OTHER, ENGLISH
-7 050-3904-XX 1 KIT:SERVICE REPLACEMENT KIT;METAL HANDLE W/
PLASTIC GRIP AND HARDWARE;MSO5 & MSO6 SERIES
-8 378-0952-XX 1 GRILL, COSMETIC, REAR, SAFETY CONTROLLED
-9 211-1573-XX 6 SCREW, CAPTIVE; M2.5 X .45 X 14 FLAT HEAD, TORX T8,
W/ DOGPOINT
-10 105-1186-XX 2 HOOK, CORD WRAP, SAFETY CONTROLLED
-11 376-0256-XX 2 COUPLER, HUB HANDLE, SAFETY CONTROLLED
-12 211-1610-XX 4 SCREW, MACHINE; M3 X 0.5 X 16, FLAT HEAD, STL,
TORX 10
-13 211-1584-XX 12 SCREW, MACHINE, M3 X 0.5 X 6MM PAN HEAD, TORX
T10
-14 214-5384-XX 2 SPRING, CORD WRAP
-15 437-0544-XX 1 TRIM, REAR I/O
-16 065-1008-XX 2 MODULE ASSY: SERVICE REPLACEMENT KIT; FLIP FEET
-17 200-5339-XX 1 DOOR, HARD DRIVE
-18 211-1585-XX 5 SCREW, DELTA-PT, 3MM X 8MM, T10
-19 050-3896-XX 1 KIT;MSO5 SERIES HANDLE HUB RIGHT
Replaceable parts
6 Series B MSO MSO64B, MSO66B, MSO68B Service 28
