Note:
None of the components listed are user-replaceable. Return the instrument to your nearest T
ektronix Service
Center to repair or replace any internal components or assemblies in this diagram.
Table 9: Mid-plane chassis
Index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont'd
Qty Name & description
Figure 7: Mid-plane chassis exploded view on page 32
-1 441-2927-XX 1 ASSEMBLY, CHASSIS, MID-PLANE
Return the instrument to T
ektronix for service.
-2 348-2298-XX 4 GASKET, CONDUCTIVE FOAM W/PSA 12MM X 29MM X
1.5MM THICK
-3 348-2361-XX 1 GASKET, CONDUCTIVE FOF WITH ELECTRICALLY
CONDUCTIVE PSA
-4 870-1386-XX 1 CIRCUIT BRD ASSY;MAIN, 8781386XX TESTED WITH
PACKAGING, MSO6XB
Return the instrument to Tektronix for service.
-5 214-5483-XX 1 HEATSINK, HEATPIPE
Return the instrument to Tektronix for service.
-6 167-4126-XX 8 IC, MEMORY, DRAM;DDR3, , 2GB 256MX72, DDR3-1866,
ECC, SODIMM 204
Return the instrument to Tektronix for service.
-7 407-5956-XX 8 BRACKET, SO-DIMM RETENTION, ASSEMBLY
Return the instrument to Tektronix for service.
-8 253-0559-XX 1 THERMAL INTERFACE MATERIAL, TEK049
Return the instrument to Tektronix for service.
-9 211-1584-XX 20 SCREW, MACHINE, M3 X 0.5 X 6MM PAN HEAD, TORX T10
-10 386-7847-XX 2 HEATSINK BACKER ASSEMBLY; TEK049
Return the instrument to Tektronix for service.
Replaceable parts
6 Series B MSO MSO64B, MSO66B, MSO68B Service 33
