Tektronix MSO70000C/DX Technical Reference

DC voltage measurement accuracy (averaged), ≥4 GHz, ≤20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch2 20 mV Vert scale setting,
+5 Div position setting, -0.4 V offset
- 567.25 mV __________ __________ - 552.75 mV
Ch2 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
+ 636.75 mV __________ __________ + 663.25 mV
Ch2 50 mV Vert scale setting,
+5 Div position setting, -0.25 V offset
- 663.25 mV __________ __________ - 636.75 mV
Ch2 100 mV Vert scale setting,
-5 Div position setting, +2.0 V offset
+ 2.764 V __________ __________ + 2.836 V
Ch2 100 mV Vert scale setting,
+5 Div position setting, -2.0 V offset
- 2.836 V __________ __________ - 2.764 V
Ch2 200 mV Vert scale setting,
-5 Div position setting, +1.25 V offset
+ 2.697 V __________ __________ + 2.803 V
Ch2 200 mV Vert scale setting,
+5 Div position setting, -1.25 V offset
- 2.803 V __________ __________ - 2.697 V
Ch2 500 mV Vert scale setting,
-5 Div position setting, 0 V offset
+ 3.394 V __________ __________ + 3.606 V
Ch2 500 mV Vert scale setting,
+5 Div position setting, 0 V offset
- 3.606 V __________ __________ - 3.394 V
Ch3 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
+ 524.75 mV __________ __________ + 535.25 mV
Ch3 10 mV Vert scale setting,
+5 Div position setting, -0.45 V offset
- 535.25 mV __________ __________ - 524.75 mV
Ch3 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
+ 552.75 mV __________ __________ + 567.25 mV
Ch3 20 mV Vert scale setting,
+5 Div position setting, -0.4 V offset
- 567.25 mV __________ __________ - 552.75 mV
Ch3 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
+ 636.75 mV __________ __________ + 663.25 mV
Ch3 50 mV Vert scale setting,
+5 Div position setting, -0.25 V offset
- 663.25 mV __________ __________ - 636.75 mV
Ch3 100 mV Vert scale setting,
-5 Div position setting, +2.0 V offset
+ 2.764 V __________ __________ + 2.836 V
Ch3 100 mV Vert scale setting,
+5 Div position setting, -2.0 V offset
- 2.836 V __________ __________ - 2.764 V
Ch3 200 mV Vert scale setting,
-5 Div position setting, +1.25 V offset
+ 2.697 V __________ __________ + 2.803 V
Ch3 200 mV Vert scale setting,
+5 Div position setting, -1.25 V offset
- 2.803 V __________ __________ - 2.697 V
Ch3 500 mV Vert scale setting,
-5 Div position setting, 0 V offset
+ 3.394 V __________ __________ + 3.606 V
Ch3 500 mV Vert scale setting,
+5 Div position setting, 0 V offset
- 3.606 V __________ __________ - 3.394 V
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 135
