Tektronix MSO70000C/DX Technical Reference

DC voltage measurement accuracy (averaged), ≥4 GHz, ≤20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch4 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
+ 524.75 mV __________ __________ + 535.25 mV
Ch4 10 mV Vert scale setting,
+5 Div position setting, -0.45 V offset
- 535.25 mV __________ __________ - 524.75 mV
Ch4 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
+ 552.75 mV __________ __________ + 567.25 mV
Ch4 20 mV Vert scale setting,
+5 Div position setting, -0.4 V offset
- 567.25 mV __________ __________ - 552.75 mV
Ch4 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
+ 636.75 mV __________ __________ + 663.25 mV
Ch4 50 mV Vert scale setting,
+5 Div position setting, -0.25 V offset
- 663.25 mV __________ __________ - 636.75 mV
Ch4 100 mV Vert scale setting,
-5 Div position setting, +2.0 V offset
+ 2.764 V __________ __________ + 2.836 V
Ch4 100 mV Vert scale setting,
+5 Div position setting, -2.0 V offset
- 2.836 V __________ __________ - 2.764 V
Ch4 200 mV Vert scale setting,
-5 Div position setting, +1.25 V offset
+ 2.697 V __________ __________ + 2.803 V
Ch4 200 mV Vert scale setting,
+5 Div position setting, -1.25 V offset
- 2.803 V __________ __________ - 2.697 V
Ch4 500 mV Vert scale setting,
-5 Div position setting, 0 V offset
+ 3.394 V __________ __________ + 3.606 V
Ch4 500 mV Vert scale setting,
+5 Div position setting, 0 V offset
- 3.606 V __________ __________ - 3.394 V
DC voltage measurement accuracy (averaged), <4 GHz models, 50 Ω
Instrument performance test Minimum Incoming Outgoing Maximum
Ch1 1 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 504.24 mV __________ __________ + 509.76 mV
Ch1 1 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 509.76 mV __________ __________ - 504.24 mV
Ch1 2 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 512.97 mV __________ __________ + 519.03 mV
Ch1 2 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 519.03 mV __________ __________ - 512.97 mV
Ch1 5 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 536.26 mV __________ __________ + 543.74 mV
Ch1 5 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 543.74 mV __________ __________ - 536.26 mV
Ch1 10 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
+ 574.19 mV __________ __________ + 585.81 mV
Ch1 10 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
- 585.81 mV __________ __________ - 574.19 mV
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
136 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
