Tektronix MSO70000C/DX

Scale setting Termination setting Offset setting
3
Generator setting Accuracy limits
-1.5 V -2.5 V -2.509 V -2.52456 V to -2.49345 V
-1.5 V -1.5 V -1.509 V -1.51856 V to -1.49945 V
-1.5 V -0.5 V -509 mV -516.56 mV to -501.45 mV
10 mV +3.5 V +3.4 V 3.43 V 3.4117 V to 3.4483 V
+3.5 V +2.4 V 2.43 V 2.4137 V to 2.4463 V
+1.5 V +2.5 V 2.515 V 2.4988 V to 2.5312 V
+1.5 V +1.5 V 1.53 V 1.5195 V to 1.5405 V
+1.5 V +0.5 V 530 mV 521.5 mV to 538.5 mV
0 V 0 V 30 mV 25.5 mV to 34.5 mV
0 V –1.0 V -970 mV -980.5 mV to -959.5 mV
0 V +1.0 V 1.03 V 1.0195 V to 1.0405 V
-3.5 V -3.4 V -3.43 V -3.4117 V to -3.4483 V
-3.5 V -2.4 V -2.43V -2.4137 V to -2.4463 V
-1.5 V -2.5 V -2.515 V -2.5312 V to -2.4988 V
-1.5 V -1.5 V -1.53 V -1.5405 V to -1.5195 V
-1.5 V -0.5 V -530 mV -538.5 mV to -521.5 mV
20 mV +3.5 V +3.4 V 3.46 V 3.4397 V to 3.4803 V
+3.5 V +2.4 V 2.46 V 2.4417 V to 2.4783 V
+1.5 V +2.5 V 2.56 V 2.5415 V to 2.5785 V
+1.5 V +1.5 V 1.56 V 1.5475 V to 1.5725 V
+1.5 V +0.5 V 560 mV 549.5 mV to 570.5 mV
0 V 0 V 60 mV 53.5 mV to 66.5 mV
0 V –1.0 V -940 mV -952.5 mV to -927.5 mV
0 V +1.0 V 1.06 V 1.0475 V to 1.0725 V
-3.5 V -3.4 V -3.46 V -3.4803 V to -3.4397 V
-3.5 V -2.4 V -2.46 V -2.4783 V to -2.4417 V
-1.5 V -2.5 V -2.56 V -2.5785 V to -2.5415 V
-1.5 V -1.5 V -1.56 V -1.5725 V to -1.5475 V
-1.5 V -0.5 V -560 mV -570.5 mV to -549.5 mV
50 mV +3.5 V +3.4 V 3.55 V 3.5237 V to 3.5763 V
+3.5 V +2.4 V 2.55 V 2.5257 V to 2.5743 V
+1.5 V +2.5 V 2.65 V 2.6255 V to 2.6745 V
+1.5 V +1.5 V 1.65 V 1.6315 V to 1.6685 V
+1.5 V +0.5 V 650 mV 633.5 mV to 666.5 mV
0 V 0 V 150 mV 137.5 mV to 162.5 mV
0 V –1.0 V -850 mV -868.5 mV to -831.5 mV
3
Set as precisely as the instrument's offset resolution permits.
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 179
