Tektronix MSO70000C/DX

Scale setting Termination setting Offset setting
3
Generator setting Accuracy limits
0 V +1.0 V 1.15 V 1.1315 V to 1.1685 V
-3.5 V -3.4 V -3.55 V -3.5763 V to -3.5237 V
-3.5 V -2.4 V -2.55 V -2.5743 V to -2.5257 V
-1.5 V -2.5 V -2.65 V -2.6745 V to -2.6255 V
-1.5 V -1.5 V -1.65 V -1.6685 V to -1.6315 V
-1.5 V -0.5 V -650 mV -666.5 mV to -633.5 mV
100 mV +3.5 V +3.4 V 3.7 V 3.6637 V to 3.7363 V
+3.5 V +2.4 V 2.7 V 2.6657 V to 2.7343 V
+1.5 V +2.5 V 2.8 V 2.7655 V to 2.8345 V
+1.5 V +1.5 V 1.8 V 1.7715 V to 1.8285 V
+1.5 V +0.5 V 800 mV 773.5 mV to 826.5 mV
0 V 0 V 300 mV 277.5 mV to 322.5 mV
0 V –1.0 V -700 mV -728.5 mV to -671.5 mV
0 V +1.0 V 1.3 V 1.2715 V to 1.3285 V
-3.5 V -3.4 V -3.7 V -3.7363 V to -3.6637 V
-3.5 V -2.4 V -2.7 V -2.7343 V to -2.6657 V
-1.5 V -2.5 V -2.8 V -2.8345 V to -2.7655 V
-1.5 V -1.5 V -1.8 V -1.8285 V to -1.7715 V
-1.5 V -0.5 V -800 mV -826.5 mV to -773.5 mV
120 mV +3.5 V +3.4 V 3.76 V 3.7197 V to 3.8003 V
+3.5 V +2.4 V 2.76 V 2.7217 V to 2.7983 V
+1.5 V +2.5 V 2.86 V 2.8215 V to 2.8985 V
+1.5 V +1.5 V 1.86 V 1.8275 V to 1.8925 V
+1.5 V +0.5 V 860 mV 829.5 mV to 890.5 mV
0 V 0 V 360 mV 333.5 mV to 386.5 mV
0 V –1.0 V -640 mV -672.5 mV to -607.5 mV
0 V +1.0 V 1.36 V 1.3275 V to 1.3925 V
-3.5 V -3.4 V -3.76 V -3.8003 V to -3.7197 V
-3.5 V -2.4 V -2.76 V -2.7983 V to -2.7217 V
-1.5 V -2.5 V -2.86 V -2.8985 V to -2.8215 V
-1.5 V -1.5 V -1.86 V -1.8925 V to -1.8275 V
-1.5 V -0.5 V -860 mV -890.5 mV to -829.5 mV
140 mV 0 V –1.0 V -580 mV -624.5 mV to -535.5 mV
0 V 0 V 420 mV 379.5 mV to 460.5 mV
0 V +1.0 V 1.42 V 1.3755 V to 1.4645 V
200 mV 0 V –1.0 V -400 mV -456.5 mV to -343.5 mV
3
Set as precisely as the instrument's offset resolution permits.
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
180 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
