Tektronix MSO70000C/DX Technical Reference

Effective bits, typical, <4 GHz
models
DPO7354C, Enhanced
bandwidth
40 GS/s Analog bandwidth setting
Input Frequency 3.5 GHz 3.0 GHz 2.5 GHz 2.0 GHz 1.0 GHz 0.5 GHz
10 MHz 5.9 bits 6.1 bits 6.2 bits 6.4 bits 6.8 bits 7.1 bits
510 MHz 5.9 bits 6.0 bits 6.1 bits 6.4 bits 6.8 bits 7.1 bits
1010 MHz 5.6 bits 5.7 bits 5.8 bits 6.1 bits 6.8 bits
1510 MHz 5.6 bits 5.8 bits 6.2 bits 6.3 bits
2010 MHz 5.8 bits 6.0 bits 6.1 bits 6.3 bits
2510 MHz 5.7 bits 5.7 bits 5.9 bits
3010 MHz 5.7 bits 5.8 bits
3510 MHz 5.6 bits
20 GS/s Analog bandwidth setting
Input Frequency 3.5 GHz 3.0 GHz 2.5 GHz 2.0 GHz 1.0 GHz 0.5 GHz
10 MHz 5.8 bits 6.0 bits 6.2 bits 6.3 bits 6.7 bits 7.0 bits
510 MHz 5.8 bits 6.0 bits 6.1 bits 6.3 bits 6.7 bits 7.0 bits
1010 MHz 5.6 bits 5.6 bits 5.7 bits 6.0 bits 6.7 bits
1510 MHz 5.6 bits 5.8 bits 6.1 bits 6.2 bits
2010 MHz 5.8 bits 6.0 bits 6.1 bits 6.2 bits
2510 MHz 5.6 bits 5.7 bits 5.8 bits
3010 MHz 5.7 bits 5.7 bits
3510 MHz 5.5 bits
10 GS/s Analog bandwidth setting
Input Frequency 3.5 GHz 3.0 GHz 2.5 GHz 2.0 GHz 1.0 GHz 0.5 GHz
10 MHz 5.8 bits 5.9 bits 6.1 bits 6.2 bits 6.7 bits 7.0 bits
510 MHz 5.7 bits 5.9 bits 6.0 bits 6.2 bits 6.7 bits 7.0 bits
1010 MHz 5.5 bits 5.6 bits 5.7 bits 6.0 bits 6.7 bits
1510 MHz 5.5 bits 5.7 bits 6.0 bits 6.1 bits
2010 MHz 5.6 bits 5.8 bits 6.0 bits 6.1 bits
2510 MHz 5.5 bits 5.6 bits 5.7 bits
3010 MHz 5.6 bits 5.7 bits
3510 MHz 5.4 bits
DPO7354C, Without enhanced
bandwidth
40 GS/s Analog bandwidth setting
Input Frequency 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 5.9 bits 6.3 bits 6.5 bits 6.6 bits
510 MHz 5.8 bits 6.3 bits
1010 MHz 5.6 bits
1510 MHz 5.6 bits
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
22 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
