40 GS/s Analog bandwidth setting
2010 MHz 5.1 bits
2510 MHz 4.6 bits
20 GS/s Analog bandwidth setting
Input Frequency 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 5.9 bits 6.3 bits 6.5 bits 6.6 bits
510 MHz 5.8 bits 6.3 bits
1010 MHz 5.6 bits
1510 MHz 5.6 bits
2010 MHz 5.2 bits
2510 MHz 4.6 bits
10 GS/s Analog bandwidth setting
Input Frequency 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
10 MHz 5.9 bits 6.3 bits 6.5 bits 6.6 bits
510 MHz 5.8 bits 6.3 bits
1010 MHz 5.6 bits
1510 MHz 5.7 bits
2010 MHz 5.7 bits
2510 MHz 5.5 bits
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 23
