Tektronix MSO70000C/DX Technical Reference

MSO/
DPO70804C,
MSO/
DPO70604C,
MSO/
DPO70404C,
where applicable
8 GHz 7 GHz 6 GHz 5 GHz 4 GHz 3 GHz
Gain Setting, full scale
100 mV 0.54 mV 0.51 mV 0.48 mV 0.45 mV 0.42 mV 0.40 mV
150 mV 0.73 mV 0.69 mV 0.64 mV 0.60 mV 0.55 mV 0.50 mV
200 mV 0.86 mV 0.80 mV 0.77 mV 0.72 mV 0.68 mV 0.60 mV
300 mV 1.34 mV 1.25 mV 1.16 mV 1.07 mV 0.98 mV 0.89 mV
400 mV 1.67 mV 1.58 mV 1.50 mV 1.41 mV 1.32 mV 1.14 mV
500 mV 1.94 mV 1.85 mV 1.76 mV 1.67 mV 1.58 mV 1.41 mV
600 mV 2.41 mV 2.29 mV 2.17 mV 2.04 mV 1.91 mV 1.70 mV
700 mV 2.87 mV 2.73 mV 2.58 mV 2.41 mV 2.23 mV 1.99 mV
800 mV 3.34 mV 3.17 mV 2.99 mV 2.77 mV 2.55 mV 2.29 mV
900 mV 3.70 mV 3.56 mV 3.34 mV 3.12 mV 2.90 mV 2.55 mV
1.0 V 4.28 mV 3.99 mV 3.83 mV 3.46 mV 3.38 mV 3.00 mV
2.0 V 8.36 mV 8.09 mV 7.48 mV 6.95 mV 6.60 mV 5.80 mV
2.5 V 10.23 mV 9.86 mV 9.20 mV 8.61 mV 8.18 mV 7.21 mV
3.0 V 12.10 mV 11.62 mV 10.92 mV 10.27 mV 9.75 mV 8.62 mV
4.0 V 16.61 mV 15.90 mV 14.99 mV 14.18 mV 12.97 mV 11.50 mV
4.5 V 18.57 mV 17.75 mV 16.78 mV 15.91 mV 14.55 mV 12.92 mV
5.0 V 20.53 mV 19.60 mV 18.58 mV 17.65 mV 16.13 mV 14.34 mV
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 33
