Tektronix MSO70000C/DX

MSO/DPO70804C, MSO/
DPO70604C, MSO/DPO70404C,
where applicable
2 GHz 1 GHz 500 MHz
Gain Setting, full scale
100 mV 0.37 mV 0.32 mV 0.24 mV
150 mV 0.46 mV 0.39 mV 0.32 mV
200 mV 0.55 mV 0.46 mV 0.40 mV
300 mV 0.78 mV 0.67 mV 0.57 mV
400 mV 1.01 mV 0.88 mV 0.76 mV
500 mV 1.23 mV 1.01 mV 0.92 mV
600 mV 1.50 mV 1.23 mV 1.10 mV
700 mV 1.76 mV 1.44 mV 1.28 mV
800 mV 2.02 mV 1.65 mV 1.45 mV
900 mV 2.24 mV 1.89 mV 1.67 mV
1.0 V 2.59 mV 2.03 mV 1.65 mV
2.0 V 5.08 mV 4.19 mV 3.66 mV
2.5 V 6.32 mV 5.20 mV 4.61 mV
3.0 V 6.32 mV 5.20 mV 4.61 mV
4.0 V 10.07 mV 8.28 mV 7.50 mV
4.5 V 10.07 mV 8.28 mV 7.50 mV
5.0 V 12.55 mV 10.31 mV 9.41 mV
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
