Tektronix MSO70000C/DX

DPO7104C Enhanced
bandwidth
20 GS/s
Step gain 1.0 GHz 0.5 GHz
500 mV/div 13.2 mV 9.7 mV
200 mV/div 5.57 mV 3.93 mV
100 mV/div 3.27 mV 2.24 mV
50 mV/div 1.36 mV 0.98 mV
20 mV/div 0.574 mV 0.408 mV
10 mV/div 0.328 mV 0.232 mV
5 mV/div 0.229 mV 0.16 mV
2 mV/div 0.135 mV 0.135 mV
1 mV/div 0.095 mV 0.095 mV
10 GS/s
Step gain 1.0 GHz 0.5 GHz
500 mV/div 14.7 mV 10.3 mV
200 mV/div 6.09 mV 4.34 mV
100 mV/div 3.55 mV 2.38 mV
50 mV/div 1.53 mV 1.05 mV
20 mV/div 0.625 mV 0.441 mV
10 mV/div 0.350 mV 0.24 mV
5 mV/div 0.236 mV 0.16 mV
2 mV/div 0.135 mV 0.135 mV
1 mV/div 0.095 mV 0.095 mV
5 GS/s
Step gain 1.0 GHz 0.5 GHz
500 mV/div 15.9 mV 10.7 mV
200 mV/div 6.71 mV 4.48 mV
100 mV/div 3.74 mV 2.46 mV
50 mV/div 1.68 mV 1.1 mV
20 mV/div 0.682 mV 0.454 mV
10 mV/div 0.378 mV 0.247 mV
5 mV/div 0.241 mV 0.16 mV
2 mV/div 0.135 mV 0.135 mV
1 mV/div 0.095 mV 0.095 mV
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 43
