Tektronix MSO70000C/DX

DPO7104C Without enhanced
bandwidth
20 GS/s
Step gain 1.0 GHz 0.5 GHz 0.025 GHz 0.02 GHz
500 mV/div 16.2 mV 15.2 mV 14.0 mV 13.3 mV
200 mV/div 6.8 mV 6.3 mV 5.7 mV 5.3 mV
100 mV/div 3.7 mV 3.4 mV 3.0 mV 2.8 mV
50 mV/div 1.7 mV 1.6 mV 1.45 mV 1.4 mV
20 mV/div 0.7 mV 0.64 mV 0.58 mV 0.55 mV
10 mV/div 0.38 mV 0.35 mV 0.3 mV 0.285 mV
5 mV/div 0.25 mV 0.21 mV 0.17 mV 0.14 mV
2 mV/div 0.15 mV 0.15 mV 0.1 mV 0.065 mV
1 mV/div 0.11 mV 0.11 mV 0.11 mV 0.04 mV
10 GS/s
Step gain 1.0 GHz 0.5 GHz 0.025 GHz 0.02 GHz
500 mV/div 16.2 mV 15.2 mV 14.0 mV 13.3 mV
200 mV/div 6.8 mV 6.3 mV 5.7 mV 5.3 mV
100 mV/div 3.7 mV 3.4 mV 3.0 mV 2.8 mV
50 mV/div 1.7 mV 1.6 mV 1.45 mV 1.4 mV
20 mV/div 0.7 mV 0.64 mV 0.58 mV 0.55 mV
10 mV/div 0.38 mV 0.35 mV 0.3 mV 0.285 mV
5 mV/div 0.25 mV 0.21 mV 0.17 mV 0.14 mV
2 mV/div 0.15 mV 0.15 mV 0.1 mV 0.065 mV
1 mV/div 0.11 mV 0.11 mV 0.11 mV 0.04 mV
5 GS/s
Step gain 1.0 GHz 0.5 GHz 0.025 GHz 0.02 GHz
500 mV/div 16.2 mV 16.2 mV 14.0 mV 13.3 mV
200 mV/div 6.8 mV 6.3 mV 5.7 mV 5.3 mV
100 mV/div 3.7 mV 3.4 mV 3.0 mV 2.8 mV
50 mV/div 1.7 mV 1.6 mV 1.45 mV 1.4 mV
20 mV/div 0.7 mV 0.64 mV 0.58 mV 0.550 mV
10 mV/div 0.38 mV 0.35 mV 0.3 mV 0.285 mV
5 mV/div 0.25 mV 0.21 mV 0.17 mV 0.14 mV
2 mV/div 0.15 mV 0.15 mV 0.1 mV 0.065 mV
1 mV/div 0.11 mV 0.11 mV 0.11 mV 0.04 mV
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
