Tektronix MSO70000C/DX

DPO7054C Enhanced
bandwidth
10 GS/s
Step gain 0.5 GHz
500 mV/div 11.9 mV
200 mV/div 5.0 mV
100 mV/div 2.75 mV
50 mV/div 1.2 mV
20 mV/div 0.5 mV
10 mV/div 0.28 mV
5 mV/div 0.185 mV
2 mV/div 0.11 mV
1 mV/div 0.09 mV
5 GS/s
Step gain 0.5 GHz
500 mV/div 13.0 mV
200 mV/div 5.35 mV
100 mV/div 2.95 mV
50 mV/div 1.35 mV
20 mV/div 0.54 mV
10 mV/div 0.3 mV
5 mV/div 0.19 mV
2 mV/div 0.11 mV
1 mV/div 0.09 mV
2.5 GS/s
Step gain 0.5 GHz
500 mV/div 15.0 mV
200 mV/div 6.2 mV
100 mV/div 3.35 mV
50 mV/div 1.56 mV
20 mV/div 0.63 mV
10 mV/div 0.375 mV
5 mV/div 0.205 mV
2 mV/div 0.11 mV
1 mV/div 0.09 mV
DPO7054C Without enhanced
bandwidth
10 GS/s
Step gain 0.5 GHz 0.025 GHz 0.02 GHz
500 mV/div 15.1 mV 14.0 mV 13.2 mV
200 mV/div 6.35 mV 5.7 mV 5.4 mV
100 mV/div 3.4 mV 2.95 mV 2.75 mV
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 45
