Tektronix MSO70000C/DX Technical Reference

Offset ranges, minimum
Volts/div setting Offset range
1 MΩ input 50 Ω input
1 mV/div to 50 mV/div ±1 V ±1 V
50.5 mV/div to 99.5 mV/div ±0.5 V ±0.5 V
100 mV/div to 500 mV/div ±10 V ±10 V
505 mV/div to 995 mV/div ±5 V ±5 V
1 V/div to 5 V/div ±100 V ±5 V
5.05 V/div to 10 V/div ±50 V Not applicable
For 50 Ω path, 1 V/div is the maximum vertical setting.
The input signal cannot exceed Max Input Voltage for the 50 Ω input path. Refer to the Max Input
Voltage specification for more information.
Position range ±5 divisions
Offset accuracy ±[0.005 × | offset - position | + DC Balance]
Both the position and constant offset term must be converted to volts by multiplying by the
appropriate volts/div term.
Number of waveforms for average
acquisition mode
2 to 10,000 waveforms
Default of 16 waveforms
DC voltage measurement accuracy
average acquisition mode
Average of ≥ 16 waveforms ±[DC Gain Accuracy × | reading – (offset -
position) | + offset accuracy + 0.1 division ]
Refer to DC Gain Accuracy for temperature
derating information.
Delta Volts between any two averages of
≥16 waveforms acquired with the same
oscilloscope setup and ambient conditions
±[DC gain accuracy × | reading | + 0.05 div]
Refer to DC Gain Accuracy for temperature
derating information.
Note: Offset, position, and the constant offset term must be converted to volts by multiplying by the
appropriate volts/div term.
The basic accuracy specification applies directly to any sample and to the following
measurements: High, Low, Max, Min, Mean, Cycle Mean, RMS, and Cycle RMS. The delta volt
accuracy specification applies to subtractive calculations involving two of these measurements.
The delta volts (difference voltage) accuracy specification applies directly to the following
measurements: Positive Overshoot, Negative Overshoot, Peak-to-Peak, and Amplitude.
DC voltage measurement
accuracy, sample acquisition
mode, typical
Analog channel input and vertical specification (cont.) Specifications (MSO/DPO5000/B Series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 79
