Tektronix MSO70000C/DX

Measurement type DC Accuracy (in volts)
Any sample ±[DC gain accuracy × | reading - (offset -
position) | + offset accuracy +0.15 div + 0.6 mV]
Refer to DC Gain Accuracy for temperature
derating information.
Delta volts between any two samples acquired
with the same oscilloscope setup and ambient
conditions
±[DC gain accuracy × | reading | + 0.15 div +
1.2 mV]
Refer to DC Gain Accuracy for temperature
derating information.
Offset, position, and the constant offset term must be converted to volts by multiplying by the
appropriate volts/div term.
Analog bandwidth 50 Ω DC
coupled
Full bandwidth, with amplitude tolerance of -3 dB and operating temperatures of ≤30 °C (86 °F).
Reduce the bandwidth by 1% for each °C above 30 °C.
Instrument SCALE range Bandwidth
MSO5204/B,
DPO5204/B
10 mV/div — 1 V/div
5 mV/div — 9.98 mV/div
2 mV/div — 4.98 mV/div
1 mV/div — 1.99 mV/div
DC to 2.00 GHz
DC to 1.50 GHz
DC to 350 MHz
DC to 175 MHz
MSO5104/B,
DPO5104/B
5 mV/div — 9.98 mV/div
2 mV/div — 4.98 mV/div
1 mV/div — 1.99 mV/div
DC to 1.00 GHz
DC to 350 MHz
DC to 175 MHz
MSO5054/B,
DPO5054/B
5 mV/div — 9.98 mV/div
2 mV/div — 4.98 mV/div
1 mV/div — 1.99 mV/div
DC to 500 MHz
DC to 350 MHz
DC to 175 MHz
MSO5034/B,
DPO5034/B
2 mV/div — 4.98 mV/div
1 mV/div — 1.99 mV/div
DC to 350 MHz
DC to 175 MHz
Analog bandwidth 1 MΩ DC
coupled
Full bandwidth, with amplitude tolerance of -3 dB and operating temperatures of ≤30 °C (86 °F).
Reduce the bandwidth by 1% for each °C above 30 °C.
Instrument SCALE range Bandwidth
MSO5204/B,
DPO5204/B,
MSO5104/B,
DPO5104/B
5 mV/div — 10 V/div DC to 500 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
1 mV/div — 1.99 mV/div DC to 175 MHz
MSO5054/B,
DPO5054/B
5 mV/div — 10 V/div DC to 500 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
1 mV/div — 1.99 mV/div DC to 175 MHz
MSO5034/B,
DPO5034/B
5 mV/div — 10 V/div DC to 350 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
1 mV/div — 1.99 mV/div DC to 175 MHz
Specifications (MSO/DPO5000/B Series) Analog channel input and vertical specification (cont.)
80 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
