Description Location
1. DVD/CD-RW drive
2. Front-panel controls
3. USB port
4. Ground terminal
5. Recovered data output
6. Recovered clock output
7. Probe compensation output
8. PROBE CALIBRATION output
9. Channel inputs
10. Auxiliary trigger input
11. Fast Edge output used for probe compensation
12. DC Probe Cal output
13. Logic probe input, inactive on DPO models. MSO capabilities
are available as a user upgradeable option on DPO70000DX
instruments.
On / Standby switch.
14. Clear button
15. Save/Recall buttons
16. Digital Channel setup menu
17. Menu Off button
18. Print screen image button
For all DPO7000C, MSO/DPO70000C, and MSO/DPO70000DX
models:
Only for MSO5000B and DPO5000B models:
For DPO7000C Series models:
Controls and connectors
70 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
