Tektronix RSA5100B Series

Replaceable parts
Table 4-2: Disp
lay and front panel
Fig. & index
number
Tektronix
part
number
Serial no.
effective
Serial no.
discont'd Qty Name & description
4-2--1 650-5583-xx 1
MODULE ASSY; DISPLAY WITH 119755000 LCD
-2 259-0155-01 1
FLEX CIRCUIT; POWER SWITCH, W/LED
-3 407-5504-00 1
BRACKET, DISPLAY FRONT; SAFETY CONTROLLED
-4 174-5807-00 1
CABLE, ASSEMBLY (DISPLAY BACKLIGHT)
-5
119-7537-00 1
TOUCH SCREEN ASSEMBLY, 10.4 IN, RESISTIVE, 5-WIRE, W/GASKETS
-6 119-7550-00 1
DISPLAY MODULE; LCD; 1024 X 768; 10.4 INCHES DIAGONAL, TFT, LED BACK LIGHT
-7
407-5548-xx 1
BRACKET, DISPLAY
-8 878-0414-00 1
CIRCUIT BD ASSY; INTERCONNECT DISPLAY ADAPTER BRD
-9 211-1050-00 16
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STEEL, ZINC FINISH, T15
-10 174-5014-00 1
CABLE ASSY,SP;DISPLAY DATA,FLAT FLEX
-11 174-5086-00 1
CA ASSY, SP; IDC, RIBBON, DISP ADAPT TO DIG INTERF, 2MM, 2X10
RSA5103
B, RSA5106B
-12 174-5087-00 1
CA ASSY,
SP; IDC, RIBBON, DISP ADAPT TO DIG INTERF, 2MM, 2X15
RSA5103B, RSA5106B
-13 348-197
9-00
1
GASKET, SET DISPLAY
-14 407-55
49-00
2
BRACKET; DISPLAY, MOUNTING
-15 211-09
50-00
4
SCREW; 6-32 X 0.25,TORX,STL
-16 814-0
207-00
1
PANEL ASSEMBLY; FRONT, RSA5XXX SERIES
-17 878-0
814-00
1
CIRCUIT BRD ASSY; RSA ENCODER
RSA5115B, RSA5126B
-18 174-5101-00 1
CA ASSY, SP; IDC, RIBBON, AUDIO COM Express PC TO DIG INTERF, 2X5
-19 174-5080-00 1
CA ASSY, SP; IDC, RIBBON, FRT PANEL TO DIG INTF, 2X10
-20 878-0417-00 1
CIRCUIT BD ASSY; USB I/O
-21 878-0749-00 1
CIRCUIT BD ASSY; FRONT PANEL CONTROL
-22 260-2903-00 1
SWITCH, KEYPAD FRONT PANEL
-23 333-4618-00 1
FRONT SUBPANEL ASSEMBLY
-24 366-A056-01 1
KNOB; GENERAL PURPOSE
-25 260-2719-00 1
SWITCH, KEYPAD; POWER BUTTON
4–6 RSA5100B Series Service Manual
