Table 74: RF flatness (Option 50/51 Preamp ON) (cont.)
Attenuator = 10 dB
Frequency
Power meter
reading
∆ Power
meter (vs.
100 MHz)
RTSA reading
(vs. 100 MHz)
30 dB
attenuator
∆30 dB
attenuator
RF flatness
error
1
16.0 GHz
16.1 GHz
16.2 GHz
16.3 GHz
16.4 GHz
16.5 GHz
16.6 GHz
16.7 GHz
16.8 GHz
16.9 GHz
17.0 GHz
17.1 GHz
17.2 GHz
17.3 GHz
17.4 GHz
17.5 GHz
17.6 GHz
17.7 GHz
17.8 GHz
17.9 GHz
18.0 GHz
18.1 GHz
18.2 GHz
18.3 GHz
18.4 GHz
18.5 GHz
18.6 GHz
18.7 GHz
18.8 GHz
18.9 GHz
19.0 GHz
19.1 GHz
19.2 GHz
19.3 GHz
