Tektronix RSA5100B Series

Specifications
Table 4: Integr
ated jitter
Characteristic Description
Integrated Phase (RMS, 1 kHz to 10 MHz), typical 1.01
e-3
radians at 1 GHz
1.23
e-3
radians at 2 GHz
1.51
e-3
radi
ans at 6 GHz
2.51
e-3
radians at 10 GHz
3.27
e-3
radians at 20 GHz
Table 5: RF input
Characteristic Description
RF Input Connector, nominal N type (RSA5103B/5106B)
Planar Crown (RSA5115B/5126B)
RF Input Impedance, nominal
50 
RF VSWR, typical
95% confidence
<1.6 (10 kHz to 10 MHz, RF ATT = 10 dB, Preamp OFF),
Center Frequency set to <200 MHz at time of test.
Preamp OFF
>10MHzto3GHz
<1.3
>3 GHz to 6.2 GHz
<1.3
>6.2 GHz to 15 GHz
<1.5
>15 GHz to 22 GHz
<1.5
RSA5115B/5126B
>22 G Hz to 26.5 GHz
<1.7
>10MHzto2GHz
<1.1
>2 GHz to 5 GHz
<1.25
RSA5103B/5106B
>5 GHz to 6.2 GHz
<1.3
Preamp ON (Option 50), RF ATT = 10 dB <1.6 (10 kHz to 10 MHz, RF ATT = 10 dB, Preamp ON),
Center Frequency set to <200 MHz at time of test.
>10MHzto3GHz
<1.4
>3 GHz to 6.2 GHz
<1.5
>6.2 GHz to 15 GHz
<1.8
>15 GHz to 22 GHz
<1.8
RSA5115B/5126B
>22 G Hz to 26.5 GHz
<2.0
10 MHz to 2 GHz
<1.2
RSA5103B/5106B
>2 GHz to 6.2 GHz
<1.4
Preamp ON (Option 50), RF ATT = 0 dB <1.6 (10 kHz to 10 M Hz, RF ATT = 0 dB, Preamp OFF),
Center Frequency set to <200 MHz at time of test.
>10MHzto2GHz
<1.5
>2 GHz to 3.0 GHz
<1.6
>3 GHz to 5.5 GHz
<1.4
RSA5103B/5106B
>5.5 GHz to 6.2 GHz
<1.75
