Tektronix RSA5100B Series

Performance Verification
Table 79: IF flat
ness
Generator
Frequency RTSA reading
Δ RTSA reading
(vs. 200 MHz)
Power meter
reading
Δ power meter
reading (vs.
200 MHz)
Calculated IF
Flatness Error
Span = 300 kHz
200 MHz 0 0 0
199.85 MHz
199.88 MHz
199.91 MHz
199.94 MHz
199.97 MHz
200.03 MHz
200.06 MH
z
200.09 MHz
200.12 MHz
200.15 M
Hz
Span = 20
MHz
200 MHz 0 0 0
190 MHz
192 MHz
194 MHz
196 MHz
198 MH
z
202 MHz
204 MHz
206 M
Hz
208 MHz
210 MHz
Span = 25 MHz
200
MHz
000
187.5 MHz
190 MHz
19
2.5 MHz
195 MHz
197.5 MHz
2
02.5 MHz
205 MHz
207.5 MHz
122 RSA5100B Series Technical Reference
