Tektronix RSA5100B Series

Specifications
Table 10: Noise and distortion
1
(cont.)
Characteristic Description
3rd Order Intermodulation Distortion, Preamp ON, typical
5
1 MHz to 120 MHz < –70 dBc
120 MHz to 300 MHz < –75 dBc
(RSA5103B/5106B)
300 MHz to 3 GHz
< –80 dBc
(RSA5103B/5106B) 3 G Hz to 6.2 GHz
< –90 dBc
1 MHz to 120 MHz < –80 dBc
120 MHz to 300 MHz < –80 dBc
300 MHz to 6.2 GHz
< –90 dBc
(RSA5115B/5126B)
6.2 GHz to 15 GHz
< –80 dBc
(RSA5126B) 15 GHz to 26.5 GHz
< –80 dBc
2
nd
Harmonic Distortion, typical. Preamp OFF
10 MHz to 500 MHz < –80 dBc
500 MHz to 1 GHz
< –80 dBc
RSA5103B/5106B)
1GHzto3.1GHz
< –83 dBc
10 MHz to 500 MHz < –80 dBc
500 MHz to 1 GHz
< –74 dBc
1GHzto3.1GHz
< –74 dBc
3.1 GHz to 7.5 GHz
< –85 dBc
RSA5115B/5126B
7.5 GHz to 13.25 GHz
< –85 dBc
2
nd
Harmonic Distortion Preamp ON, typical
10 MHz to 13.25 GHz
< –50 dBc
2
nd
Harmonic Distortion Intercept (SHI), typical
10 MHz to 500 MHz +45 dBm
500 MHz to 1 GHz
+34 dBm
1GHzto3.1GHz
+34 dBm
3.1 GHz to 7.5 GHz
+45 dBm
7.5 GHz to 13.25 GHz
+45 dBm
2
nd
Harmonic Distortion Intercept (SHI) Preamp ON, typical
10 MHz to 13.25 GHz
+10 dBm
12 RSA5100B Series Technical Reference
